Excellent for groundwater remediation & other applications!
| Applies To All Water Treatment Containers & Drums | |||||
| Drum Size | 5 gal. (Plastic) | 10 gal. (Plastic) | 25 gal. (Plastic) | 55 gal. (Plastic) | 55 gal. (Metal) |
| Industrial Applications | 2.52 gpm @ 3 gpm/ft sq. | 3.69 gpm @ 3 gpm/ft sq. | 6.06 gpm @ 3 gpm/ft sq. | 10 gpm @ 3.62 gpm/ft sq. | 10 gpm @ 3.62 gpm/ft sq. |
| Commercial Water Applications | 4.20 gpm @ 5 gpm/ft sq. | 6.15 gpm @ 5 gpm/ft sq. | 10.1 gpm @ 5 gpm/ft sq. | 12 gpm @ 4.35 gpm/ft sq. | 12 gpm @ 4.35 gpm/ft sq. |
| Residence Time | 2.38 min. @ 2.5 GPM | 2.81 min. @ 3.7 GPM | 4.17 min. @ 6 GPM | 4.50 min. @ 10 GPM | 4.50 min. @ 10 GPM |
| Inlet & Outlet | 3/4″ FNPT | 1″ FNPT | 1 1/4″ FNPT | 1 /2″ FNPT | 2″ FNPT |
| UltraSorber-BC™, General Contaminents Of Low & High Mol Weight Removal Media: Bituminous Coal Based Carbon | |||||
| Part Number | 90-008-5P | 90-008-10P | 90-008-25P | 90-008-55P | 90-008-55M |
| Drum Size | 5 Gallon | 10 Gallon | 25 Gallon | 55 Gallon | 55 Gallon |
| Drum Material | Plastic | Plastic | Plastic | Plastic | Metal |
| Bulk Density (lbs/cf) | 27.5 | 27.5 | 27.5 | 27.5 | 27.5 |
| Mesh Size | 8 x 30 | 8 x 30 | 8 x 30 | 8 x 30 | 8 x 30 |
| Approx. Media Weight (lbs) | 11 | 28 | 86 | 165 | 165 |
| Flow Rate (gpm) | 2.5 | 3.7 | 6 | 10 | 10 |
| Max. Pressure (psi) | 1 | 1 | 1 | 8 | 8 |
